Ferromagnetic detection at the magnet room door
An MRI magnet is always on, and a ferromagnetic object carried into the fringe field becomes a projectile. Our detection system provides a last technical check at the Zone III to Zone IV boundary, supplementing the screening procedure rather than replacing it.
Detection principle
- Passive magnetometry — senses distortion of the ambient magnetic field
- Emits no field of its own, so it cannot interfere with imaging
- Responds only to ferromagnetic material, not to aluminium, titanium or coins
- Detects material in motion through the sensing region
Sensing & discrimination
- Vertical magnetometer array for consistent coverage floor to head height
- Approximate height of the detected object indicated
- Signal processing to reject ambient noise — lift motors, corridor traffic, door mechanisms and building steel
- Adjustable sensitivity threshold to balance detection against nuisance alarms
Alarm & indication
- Visual and audible alarm on detection
- Clear at-a-glance status readable under stress
- Self-test and calibration so faults are visible rather than silent
Installation & integration
- Sited at the Zone III to Zone IV boundary, at the magnet room entrance
- Electronics designed to operate within the magnet fringe field
- Interfacing to door interlocks, access control and event logging
- Siting guidance to keep the unit clear of moving building metal
Scope & limitations
- Supplements screening, questionnaires, zoning and staff training
- Detects moving ferromagnetic material, not stationary objects
- Does not characterise implants — implant screening remains a documented questioning process
- Indicates that ferromagnetic mass is present, not what the object is
